Description
Overview:
High-Horsepower street cars and truck can be a challenge to keep cool. A proper cooling system starts with the right radiator. Aluminum Radiators cool more effectively and weight less than older OEM style brass units. Choose from a variety of popular application specific fitments.Holley is proud to introduce its latest offering – Frostbite Performance Cooling Products.When it comes to keeping your ride cool, Make it Frostbite!17″ Tall Core Radiators fit trucks that came from the factory w/ the upper mounts that bolt-on behind the cowl.19″ Tall Core radiators fits trucks that came from the factory with upper mounts that bolt-on top of the cowl.
Features:
- 100% TIG welded (brazed) seams
- Aircraft quality aluminum core, fittings, and tanks (up to 30% weight savings)
- Dual Pass, Cross Flow design to maximize cooling efficiency
- Billet Aluminum Filler Neck and OEM style Brass Petcock
- More cooling fins per inch for more efficient cooling
- Custom Frostbite High Performance 16lb. radiator cap
- Polished top and tanks for custom show appearance
- 3-Row Radiators supporting applications with 600+ horsepower
- Applications for GM, Ford, Dodge/Chrysler/Jeep and LS-Swap available
- Manufacturer’s 1-year Limited Warranty
Application:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| 1970 | Pontiac | Tempest | Base | 250/4.1L L6 |
| 1987 | Chevrolet | R10 | 262/4.3L V6 | |
| 1987 | Chevrolet | R10 | 305/5L V8 | |
| 1973 | Chevrolet | C10 Pickup | 307/5L V8 | |
| 1968 | Chevrolet | Chevelle | 327/5.3L V8 | |
| 1968 | Chevrolet | Chevelle | 327/5.4L V8 | |
| 1968 | Pontiac | Tempest | 350/5.7L V8 | |
| 1970 | Pontiac | Tempest | Base | 350/5.7L V8 |
| 1973 | Pontiac | LeMans | Safari | 350/5.7L V8 |
| 1987 | Chevrolet | R10 | 350/5.7L V8 | |
| 1987 | Chevrolet | R10 | 379/6.2L V8 | |
| 1970 | Pontiac | Tempest | Base | 400/6.6L V8 |
| 1968 | Buick | Skylark | 400/6.6L V8 | |
| 1968 – 1969 | Chevrolet | Chevelle | 230/3.8L L6 | |
| 1968 – 1969 | Pontiac | Tempest | 250/4.1L L6 | |
| 1968 – 1969 | Buick | Special | 250/4.1L L6 | |
| 1973 – 1974 | Chevrolet | C10 Pickup | 250/4.1L L6 | |
| 1985 – 1986 | Chevrolet | C10 | 262/4.3L V6 | |
| 1973 – 1974 | Chevrolet | C10 Pickup | 292/4.8L L6 | |
| 1970 – 1971 | Chevrolet | Camaro | RS | 307/5L V8 |
| 1968 – 1969 | Buick | Special | 350/5.7L V8 | |
| 1968 – 1969 | Buick | GS 350 | 350/5.7L V8 | |
| 1973 – 1974 | Chevrolet | C10 Pickup | 350/5.7L V8 | |
| 1968 – 1969 | Pontiac | Tempest | 400/6.6L V8 | |
| 1968 – 1969 | Buick | GS 400 | 400/6.6L V8 | |
| 1968 – 1969 | Pontiac | Grand Prix | 428/7L V8 | |
| 1973 – 1974 | Chevrolet | C10 Pickup | 454/7.4L V8 | |
| 1970 – 1971 | Buick | Skylark | 455/7.5L V8 | |
| 1970 – 1972 | Buick | GS | 350/5.7L V8 | |
| 1970 – 1972 | Chevrolet | Monte Carlo | 350/5.7L V8 | |
| 1968 – 1970 | Chevrolet | Chevelle | 396/6.5L V8 | |
| 1970 – 1972 | Chevrolet | Monte Carlo | 400/6.6L V8 | |
| 1970 – 1972 | Chevrolet | Chevelle | 400/6.6L V8 | |
| 1970 – 1972 | Chevrolet | Chevelle | 402/6.6L V8 | |
| 1970 – 1972 | Chevrolet | Monte Carlo | 402/6.6L V8 | |
| 1970 – 1972 | Chevrolet | Monte Carlo | 454/7.4L V8 | |
| 1970 – 1972 | Chevrolet | Chevelle | 454/7.4L V8 | |
| 1970 – 1972 | Pontiac | LeMans | 455/7.5L V8 | |
| 1970 – 1972 | Buick | GS 455 | 455/7.5L V8 | |
| 1970 – 1972 | Pontiac | Grand Prix | 455/7.5L V8 | |
| 1970 – 1972 | Pontiac | GTO | 455/7.5L V8 | |
| 1968 – 1971 | Buick | Skylark | 250/4.1L L6 | |
| 1968 – 1972 | Chevrolet | Chevelle | 250/4.1L L6 | |
| 1968 – 1972 | Pontiac | LeMans | 250/4.1L L6 | |
| 1968 – 1972 | Chevrolet | Chevelle | 307/5L V8 | |
| 1968 – 1972 | Buick | Skylark | 350/5.7L V8 | |
| 1968 – 1972 | Pontiac | LeMans | 350/5.7L V8 | |
| 1968 – 1972 | Chevrolet | Chevelle | 350/5.7L V8 | |
| 1982 – 1986 | Chevrolet | C10 | 379/6.2L V8 | |
| 1976 – 1980 | Chevrolet | C10 | 400/6.6L V8 | |
| 1968 – 1972 | Pontiac | Grand Prix | 400/6.6L V8 | |
| 1968 – 1972 | Pontiac | LeMans | 400/6.6L V8 | |
| 1968 – 1972 | Pontiac | GTO | 400/6.6L V8 | |
| 1975 – 1980 | Chevrolet | C10 | 292/4.8L L6 | |
| 1975 – 1980 | Chevrolet | C10 | 454/7.4L V8 | |
| 1975 – 1984 | Chevrolet | C10 | 250/4.1L L6 | |
| 1977 – 1986 | Chevrolet | C10 | 305/5L V8 | |
| 1975 – 1986 | Chevrolet | C10 | 350/5.7L V8 |
Specs:
| # of Passes | Dual |
|---|---|
| Brand | Frostbite |
| Choose Your Part | Radiators |
| Cooling Row Diameter | 11/16″ |
| Core Dimension | 17 x 28 1/4 |
| Core Thickness | 2.20″ |
| Emission Code | 5 |
| Flow Style | Dual Pass |
| Hose Location Inlet | Passenger |
| Hose Location Outlet | Passenger |
| Inlet / Outlet Size | AN Bungs |
| Inlet Size | AN Bungs |
| Mounting Type | Saddle Mount |
| Outlet Size | AN Bungs |
| Overall Dimension | 18-1/2 x 33 |
| Product Type | Radiators |
| Rows | 3 |
| Steam Port Fitting Size | 1/4″ NPT |
| Transcooler Provision | No |
