Description
Overview:
Earl’s billet side mount oil cooler adapters are the slick way to add an oil cooler to your GM LS or Gen-V LT engine.The slim design of these adapters clear most headers and other components and feature -10 AN male connections.These adapters are black anodized and use O-Ring seals for a leak free installation.Choose from a standard adapter or one with a thermostat (212 degree is standard & optional 210 thermostat is available separately).
Features:
- Billet Aluminum w/ Black Anodized Finish
- Includes 0-Ring Seal & Hardware
- (2) 1/8” NPT Accessory Ports
- -10 AN Male Connections
- Available w/ 212 Degree Thermostat
- Add an Earl’s Oil Cooler and AN Plumbing to Complete the Installation
Application:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| 2001 – 2004 | Chevrolet | Corvette | Base | 350/5.7 V8 |
| 2001 – 2004 | Chevrolet | Corvette | Z06 | 350/5.7 V8 |
| 2004 – 2006 | Pontiac | GTO | / | |
| 2004 – 2005 | Cadillac | CTS | V | 346/5.7 V8 |
| 1997 – 2005 | Chevrolet | Corvette | / | |
| 2005 – 2006 | Chevrolet | SSR | / | |
| 2005 – 2008 | Pontiac | Grand Prix | GXP | 325/5.3 V8 |
| 2006 – 2009 | Chevrolet | Impala | SS | 325/5.3 V8 |
| 2006 – 2007 | Cadillac | CTS | V | 364/6 V8 |
| 2006 – 2007 | Chevrolet | Corvette | Base | 364/6 V8 |
| 2006 – 2013 | Chevrolet | Corvette | Z06 | 427/7 V8 |
| 2006 – 2009 | Chevrolet | Trailblazer | SS | 364/6 V8 |
| 2006 – 2007 | Chevrolet | Monte Carlo | SS | 325/5.3 V8 |
| 2008 – 2009 | Buick | LaCrosse | Super | 325/5.3 V8 |
| 2008 – 2013 | Chevrolet | Corvette | Base | 376/6.2 V8 |
| 2008 | Chevrolet | Corvette | 427 Limited Edition Z06 | 427/7 V8 |
| 2001 – 2004 | Avanti | II | / | |
| 2008 – 2009 | Buick | Allure | Super | 325/5.3 V8 |
| 2009 – 2015 | Cadillac | CTS | V | 376/6.2 V8 |
| 2009 – 2013 | Chevrolet | Corvette | ZR1 | 376/6.2 V8 |
| 2009 | Pontiac | G8 | GXP | 376/6.2 V8 |
| 2010 – 2015 | Chevrolet | Camaro | SS | 376/6.2 V8 |
| 2010 – 2013 | Chevrolet | Corvette | Grand Sport | 376/6.2 V8 |
| 2011 | Chevrolet | Corvette | Z06 Carbon | 427/7 V8 |
| 2012 – 2015 | Chevrolet | Camaro | ZL1 | 376/6.2 V8 |
| 2013 | Chevrolet | Corvette | 427 | 427/7 V8 |
| 1998 – 2002 | Chevrolet | Camaro | Z28 | 350/5.7 V8 |
| 1998 – 2002 | Chevrolet | Camaro | Z28 SS | 350/5.7 V8 |
| 2003 | Chevrolet | Corvette | 50th Anniversary Edition | 350/5.7 V8 |
| 2003 | Chevrolet | Corvette | 50th Anniversary Edition Pace Car | 350/5.7 V8 |
| 1998 – 2002 | Pontiac | Firebird | Formula | 350/5.7 V8 |
| 1998 – 2002 | Pontiac | Firebird | Trans Am | 350/5.7 V8 |
| 2014 – 2015 | Chevrolet | Camaro | Z/28 | 427/7 V8 |
| 2015 – 2017 | Chevrolet | SS | 376/6.2 V8 | |
| 2014 | Chevrolet | SS | / |
Specs:
| Adapter AN Size ( A ) | 10 AN MALE |
|---|---|
| Adapter AN Size ( B ) | 10 AN MALE |
| Adapter NPT Size ( C ) | 1/8 NPT FEMALE |
| Brand | Earls |
| Emission Code | 5 |
| Finish | Anodized Black |
| Material | Billet Aluminum |
| Product Type | Oil Cooler |
