Description
Overview:
Holley marine mechanical fuel pumps range from 110 GPH to 200 GPH forsmall and big block Chevy applications to meet the fuel demands of most engines. Holley Marine mechanical pumps are designed with a fuel/fume tube to provide a safe fuel exit in the unlikely event of a diaphragm rupture.
Features:
- High output fuel flow
- Flows 130+ GPH free flow
- Shutoff pressure pre-set from 7.5 to 9 psi
- Fuel pressure regulator is required (recommend Holley P/N 12-704)
- Heavy duty construction for continuous high rpm operation
- Redesigned high flow valves always ensure adequate fuel delivery
- Fuel body casting can be rotated to accommodate various plumbing situations
- Inlet & outlet tapped for 3/8″ NPT
- Includes Fuel/vapor tube
Application:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| Universal |
Specs:
| Application | Marine BBC |
|---|---|
| Brand | Holley |
| Color | Silver |
| Emission Code | 5 |
| Free Flow GPH | 130 |
| Free Flow LPH | 416 |
| Fuel Pump Type | Mechanical |
| Fuel Type | Gasoline |
| Inlet Size | 3/8 inch NPT |
| Material | Aluminum |
| Outlet Size | 3/8 inch NPT |
| Product Type | Fuel Pump |
| Warning | California Proposition 65 |
| Warranty | Limited 90 Day |
